Electron Source: Tungsten hairpin filament (standard) or optionally

.

Resolution: 3.5 nm at 30 kV (high vacuum), 5.5 nm at 30 kV (BSD-VP mode).

Variable Pressure: 1 Pa to 400 Pa (allows imaging of non-conductive, hydrated samples).

Accelerating Voltage: 0.2 kV to 30 kV.

Magnification: 9x to 900,000x.

Probe Current: 1 pA to

 (Optibeam controlled).

Detector: Everhart Thornley SE detector with Variable Pressure Secondary Electron (VPSE) detector.

Chamber Size: 300 mm x 270 mm x 224 mm, optimized for large samples.

Stage: 5-axis motorized (X=100mm, Y=125mm, Z=60mm, Tilt 0-90°, Rotation 360°).

With Turbo Pump
